E0503 148 × 210 mm
Wireless Weather Station + Sensor
GB
The weather station is equipped with a touchscreen.
The weather station displays clock, two alarm times with snooze function, the weather forecast, information about the indoor and outdoor temperature
and humidity and the moon phase.
The minimum and maximum measured values are stored.
Before you start using the product read the user manual carefully.

Specification:

• Radio controlled clock (DCF)
• Indoor temperature: from 0 °C to +50 °C
Accuracy: ±1 °C (from 0 °C to +40 °C), ±2 °C (from +40 °C to +50 °C)
• Outdoor temperature: from -40 °C to +50 °C
Accuracy: ±1 °C (from 0 °C to +40 °C), ±2 °C (from -40 °C to 0 °C, from
+40 °C to +50 °C)
• Temperature differentiation: 0,1 °C
• Indoor humidity: from 20 % to 99 %
Accuracy: ±5% (from 40 % to 80 %) or ±8%
• Outdoor humidity: from 20 % to 90 %
Accuracy: ±5% (from 40 % to 80 %) or ±8%
• Remote sensor: transmitting frequency 868 MHz
• Transmission distance: max. 65 m in an opened area
• No. of sensors: max. 3
• Power:
The main unit: 2× 1.5V AAA batteries (not included)
Sensor: 2× 1.5V AA batteries (not included)
• Dimensions and Weight:
The main unit: 144 × 103 × 20 mm
Sensor: 53 × 105 × 23 mm
The Layout of Icons and Buttons
A – The Pressure Trend Arrow
B – The Weather Forecast Icon
C – The Moon Phase Icon
D – The Icon of Discharged Battery in the Weather Station
E – The DCF 77 Radio Signal reception Icon
F – Current Time
G – The Alarm Clock Icon
H – The number of the Sensor
I – The Icon of Graduate Displaying of Data from All Connected Sen-
sors
J – The Icon of Maximum Value Measured Outdoor Temperature and
Humidity
K – The Icon of Minimum Value Measured Outdoor Temperature and
Humidity
L – The Icon of Measured Value of Indoor Temperature and Humidity
- to the left of this icon the outdoor temperature and humidity is
displayed -
M – The Icon of Maximum Value Measured Indoor Temperature and
Humidity
N – The Icon of Minimum Value Measured Indoor Temperature and
Humidity
Buttons If the Button is Pressed
SNOOZE display backlight
activation
touchscreen buttons
activation
activation/deactivation
of the alarm clock No. 1,
No. 2 / one step forward
activation/deactivation
of the alarm clock No. 1,
No. 2 / one step back
MODE displaying the day/date/
alarm clock time/time
CH displaying the sensor
No. 1, 2, 3
MEM displaying max/min
values of temperature
and humidity
Sensor
Front Side Back Side
A – LED of transmission of signal from the sensor
B – outdoor temperature
C – No. of sensor, outdoor humidity
D – opening for hanging on the wall
Buttons Under the Battery Cover:
CH – setting the sensor's channel
RESET – sensor's values deletion
To display the touchscreen buttons press
SNOOZE!

Putting into Operation

1. Insert the batteries into the station (2× AAA) and then into the remote
sensor (2× AA). When inserting the batteries observe the right polarity
of the batteries to avoid the weather station or sensor damage. Use
the alkaline batteries of the same kind only, do not use the recharge-
able batteries.
2. Place the both units next to each other. The weather station captures
the signal from the sensor within 2 minutes. In case the signal from
the sensor has not been found, hold the CH button on the weather
station to repeat the operation.
2
If Holding the button
basic settings
searches the signal from
the sensor
deletion of measured
values/searches the DCF
77 signal
Removing the battery cover
