US Blaster 7135 Beschreibung

DESCRIPTION :
- Multifunctional colour screen display
- Digital karaoke system
- HI-FI Stereo design
- Circle transformers supply, high power
- Dual profession VHF wireless microphones
DESCRIPTION OF FUNCTIONS :
Front panel :
ON
POWER
OFF
5 C H A N N E L D I G I T A L A M P L I F I E R W I T H
M . VO LU ME
M I C2
M I C1
-
1 2 3
1) Power switch
Use this switch to switch your device on.
2) Micro input
Input Jack 6.35mm. Plug you microphone on.
3) Microphone volume control
Use to adjust the level of the microphone
4) Microphone treble control knob
This potentiometer allows you to adjust the high
tone of the microphone.
5) Screen display
6) Microphone bass control knob
This potentiometer allows you to adjust the low
tone of the microphone.
7) VCD/DVD input selection
Use to select the item plug in the VCD/DVD
input
8) CD1 input selection
Use to select the item plug in the CD 1 input
9) TUNER /AUX input selection
Use to select the item plug in the Tuner input
10) TAPE input selection
Use to select the item plug in the tape input
P R O F E S S I O N A L V H F M I C R O P H O N E
VCD/ DVD TUNE R / AUX R E S E T
M . B A SS
M . T REBLE
CD1
- + - +
+
4 5 6 7 8 9 10 11 12 13 14 15
KARAOK E ON
E CHO BALANCEBASS T RE B LE
TAPE CD2 KARAOK E OFF
+
-
11) RESET key
Use to reset all the setup you make ( echo,
balance, volume, ... )
12) CD2 input selection
Use to select the item plug in the CD 2 input
13) Karaoké off selection key
Use to switch the karaoke function off.
14) Karaoké on selection key
Use to switch the karaoke function on.
15) Echo control knob
Use to adjust the deepth of the echo
16) Balance control knob
Use to adjust the left/right level of the master
speakers.
17) Bass control knob
This potentiometer is used to adjust the low tone
od the master signal
18) Treble control knob
This potentiometer is used to adjust the high
tone od the master signal
19) Master volume
Use to adjust the level of the master signal.
VOLUM E
d i g i t al
cl n e m a
s o un d
M I N MAX
- + - +
L R
17 18 19
16
