1 Horizontal adjustment
Pull lever completely and move seat forwards/backwards.
Release the lever to lock the seat.
2 Weight- and height adjustment
Press button and adjust the height in desired height.
Don't adjust the height so softly that on rough roads the seat
will knock through.
3 Seat cushion adjustment
Pull lever and move the seat cushion forward/backward.
Release the lever to lock the seat.
4
Tilt adjustment
Pull lever and adjust the tilt by loading/unloading the front seat
cushion area.
5
Heating (optional)
Thermostatic regulated heating for seat cushion and backrest.
To switched on resp. off by switch.
6 Lumbar support/ Integrated pneumatic system (IPS)
(optional)
Press button to match the shape of the backrest individually to the
body contours.
Backrest adjustment
7
Pull handle and adjust the backrest position by applying your
weight to the backrest.
8
Armrest (optional)
Lift up armrest a little and adjust inclination by turning the wheel.
9
3-point-belt (optional)
Don't twist the seat belt when fastening.
Make sure that the belt tongue engages correctly in the belt buckle.
The belt has to rest close against the body.
When unfasten, guide the belt tongue back to the belt exit
backrest.
7018574/Rev.30.07.2013
8
4
3
14 in the
2
1
2 Weight- and height adjustment

optional equipment

6 Lumbar support/ Integrated
pneumatic system (IPS)
upper
air chamber
9
3-Point-Belt
7
6
5
D
GB
lower
air chamber
Side support
(only IPS)
