Status LEDs
EtherXtend 30x4 Quick Installation Guide
4
Table 2:
LED
Color
power
Green
status
Green
alarm
Red
co mode
Yellow
DSL 1, 2, 3, 4
Green
LAN Status*
Green
1,2,3,4
LAN Rate*
Green
1,2,3,4
* This LED is on the back panel.
State
Description
On
Power applied
Off
Power turned off
On
Device has rebooted, or system
error has been detected
Blinking
Normal operation - Short blink
every 3 seconds
On
Unit has just been reset or an
alarm condition exists
Off
Normal operation
On
Device is in CO mode
Off
Device is in CPE mode
On
Link is up
Off
Link is down
On
Link is up
Off
Link is down
Blinking
Activity on the Link
On
100 Mbps
Off
10 Mbps
