3 - FRONT OF THE Espas30 I STATION

All the elements required to operate the station are located on the front panel, at a suitable
height so that a driver can easily perform all the necessary operations.
A - Intercom call button (optional)
B - 20x2 alphanumeric LCD display
to display instruction messages
C - Illuminated anti-tampering button
to issue the parking ticket
D - 125KHz RFID proximity reader
for operators' cards
E - Parking ticket issue slot
F - Season ticket reading
scanner (only versions
with scanner at entry)

4 - OPERATION

The Espas30 I station can operate in the following modes:

Operating mode

NORMAL
ONLY CARD
ONLY TICKET
AUTOMATIC
OPEN
CLOSED
It is possible to set the operating mode using the menu of the Deneb board. Follow the
instructions in chapter 13- CONFIGURATION MENU STRUCTURE.
Description
The station is enabled to grant access to occasional users
(who are required to collect a ticket), operators (that have
to use their own card) and season ticket holders (who are
required to insert their season ticket)
Only season ticket holders are allowed
Season ticket holders are not allowed
The barrier lifts as soon as the vehicle enters the detection
loop on the front of the station and closes once the vehicle
has passed.
The barrier is always open.
No vehicle is allowed in.
A
B
C
D
F
E
Espas30 I - 25
