B. The heater will not operate if the timer is set to the
activated according to the times required.
C. If the heater loses its electricity supply, e.g. is switched off at the mains socket or in the
event of a power failure, the time should be reset once the power is back on again.
ASSEMBLY
• Do not use the radiator without the supporting feet or if they are not mounted correctly.
1. Screw off the wing nuts from the U-shaped bolt provided.
2. Attach the U-shaped bolt to the U-facing flange between first and second fins.
3. To attach the castor mounting plate to the radiator body, you should insert the thread-
ed ends of the U bolt through the holes on the castor mounting plate.
4. Screw the wing nuts back to the U bolt and fasten the wing nut properly.
Note: do not over tighten, which may cause the damage of radiator flange.
5. Screw off spherical nut from the castor, align the shaft to the hole of the castor mount-
ing plate, insert in, and screw on the spherical nut.
6. Repeat 2, 3, 4 and 5 on the rear of radiator for mounting of the rear castors.
Note: the rear castor mounting plate must be mounted between the end two fins.
USE
• Set the thermostat knob to the minimum position and insert the plug in an electrical outlet.
• The thermostat automatically adjusts the desired room temperature.
• Turn the thermostat knob clockwise until you hear an audible click. The sound indi-
cates that the thermostat is activated and the indicator lamp illuminates. Continue to
turn the thermostat knob clockwise to the highest setting.
• The thermostat switches the indicator lamp on and off repeatedly.
• The adjusted temperature can be raised by turning the thermostat clockwise. Turning
the thermostat knob anticlockwise adjusts a lower temperature. Then the thermostat
automatically raises or lowers the temperature.
• The room to be heated up must be well-insulated. If the insulation is poor, the heat
escapes and the heating is inefficient.
• After use, turn the thermostat knob down to the minimum position and pull the plug
out of the electrical outlet.
