Connecting to the transmitter

1 Connect receiver to the mains power grid and make sure that the transmitter is switched on.
Shortly press FUNCTION on the transmitter.
2
The LEDs on the transmitter and receiver flash quickly until the wireless connection is established. Once
connected, the LEDs flash slowly.
The assignment of the receiver to the transmitter is kept memorized even after disconnecting the power
supply.
You can assign additional receivers to the transmitter at any time, even during operation. In an operational
system, assigning an additional receiver will make the connected units revert to idle mode for 10 seconds;
they will be reactivated once the new units are connected.

Disconnecting from the transmitter

Press FUNCTION on the receivers for about three seconds.
The LED goes off on and the receiver is unlinked.
Power supply:
Power consumption:
IP classification:
DMX channels:
Carrier frequency:
Modulation:
Coverage:
Antenna:
DMX connector:
Dimensions with antenna (L x W x H): 135 x 100 x 90 mm
Weight:
Specifications are subject to change without notice due to product improvements.
Accessories:
Item no. 51834023
Item no. 51834024
Disposal of old equipment
When to be definitively put out of operation, take the product to a local recycling plant for a disposal
which is not harmful to the environment. Devices marked with this symbol must not be disposed of as
household waste. Contact your retailer or local authorities for more information. Remove any inserted
batteries and dispose of them separately from the product.
You as the end user are required by law (Battery Ordinance) to return all used batteries/rechargeable
batteries. Disposing of them in the household waste is prohibited. You may return your used batteries
free of charge to collection points in your municipality and anywhere where batteries/rechargeable
batteries are sold. By disposing of used devices and batteries correctly, you contribute to the
protection of the environment.

OPERATION

TECHNICAL SPECIFICATIONS

WDR-G5
230 V AC, 50 Hz
3 W
IP65
512 (1 universe)
2.4 GHz ISM band
AFHSS
up to 500 m (line-of-sight)
5 dBi
3-pin XLR (pin 1: ground, pin 2: signal -, pin 3: signal +)
0.9 kg
FUTURELIGHT WDR-G4 RX Wireless-DMX-Receiver
FUTURELIGHT WDS-G4 Duo TX Wireless DMX Transceiver

PROTECTING THE ENVIRONMENT

14 • EN
