Technical Data; Instrument-Specific Data; Dimensions And Component-Layout Plan; Scope Of Delivery - Lenze 2003 Betriebsanleitung

2
2.1
Versorgungsspannung
Current consumption
min. acceleration time
max. acceleration time
Ambient temperature
2.2
2003
2.3
The delivery comprises:
• 2003 setpoint integrator
• Assembly kit for attachment to 470 / 480 controllers
• Operating Instructions
18

Technical data

Instrument-specific data

V
I
T
i min
T
i max
T
amb

Dimensions and component-layout plan

a b
[mm] [mm]
100 85

Scope of delivery

±15 V
7 mA
0.1 s
10 s
0...45 °C
c d e
[mm] [mm] [mm]
65 100 90
f
[mm]
72.5
