Parts List & Operating Instructions
Item
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
27
28
29
30
31
32
33
34
35
36
37
38
39
© US Service Solutions, LLC
Part
No.
No.
Req'd
537197
1
Cover
*
2
Washer—for 1/4 inch bolt
*
2
Cap Screw—1/4-20 UNC x 15.9 mm (.625 in.) lg.
*
1
Spring Pin—12 mm x 65 mm (.50 in. x 2.56 in.)
*
4
Nut—5/8-11 UNC
537205
1
Mounting Plate
539591
1
Plate
*
4
Cap Screw—5/8-11 UNC x 44.5 mm (1.75 in.) lg.
*
1
Grooved Pin—6 mm x 60 mm (.25 in. x 2.36 in.)
537202
1
Support Plate
537192
1
Rod
537199
1
Outer Post
*
4
Cap Screw—1/2-13 UNC x 101.6 mm (4.0 in.) lg.
*
2
Cap Screw—1/2-13 UNC x 38.1 mm (1.50 in.) lg.
538578
4
Universal Arm Assembly
12926
1
Motor-Rotor Decal
*
8
Cap Screw—3/8-16 UNC x 19 mm (.75 in.) lg.
537200
1
Lower Frame
*
6
Washer—for 1/2 inch bolt
*
6
Nut—1/2-13 UNC
*
2
Nut—3/8-16 UNC
*
2
Lockwasher—for 3/8 inch bolt
541027
2
Swivel Caster
*
2
Washer—for 3/8 inch bolt
*
4
Lockwasher—for 1/2 inch bolt
*
2
Locknut—5/8-11 UNC
*
2
Washer—for 5/8 inch bolt
541032
2
Wheel
537196
2
Wheel Lock
206182
1
Decal
537203
1
Rear Axle
*
2
Cap Screw—3/8-16 UNC x 88.9 mm (3.50 in.) lg.
11280
1
Decal
537201
1
Inner Post
*
1
Grease Fitting
538576
1
Warning / Logo Decal
*
1
Spring Pin—8 mm x 65 mm (.315 in. x 2.56 in.)
*
8
Locknut—3/8-16 UNC
Description
Sheet No.
Issue Date:
Form No. 565726
CAUTION: To prevent
equipment failure,
replacement hardware
must be Grade 2 or better.
Cap screws must be
SAE Grade 5 or
Metric Property Class 8.8.
Items marked with an
asterisk (*) are contained in
Hardware Kit No. 549844.
4 of 5
Rev. A August 9, 2012
