Instruction for Rollei Rock Solid Video Head
6
1
Video Pin
2
1/4" Camera Screw
50 mm movement lenght
3
Safty Lock
4
Spirit Level for horrizontal positio-
ning
5
180° Tilting Lock with friction
function
6
Panning Lock
7
Handle
1
2
3
4
5
6
7
ENGLISH
8
Removalbe sliding plate with „Auto
Lock" retainig system. It can slide
+40/-22mm to control long lenses
when adjusting for the center of
gravity.
9
Sliding Plate
10
Sliding Plate Lock
11
Handle Lock
8
9
10
11
Two Handle Position
Handle can be installed on either
side for right or left-hand operation.
