Attention!
(Important for your own security) Before starting to
run your new submersible pump, please have the
following items checked by an expert:
Ground connection
▪
Zero conductor
▪
Fault current breaker switch must correspond
▪
with the safety regulations of the power
plants and they must work faultlessly.
The electrical connections must be protected
▪
from moisture.
If there is danger of flooding, the electrical
▪
connections must be taken to higher ground.
Circulation of aggressive fluids, as well as the
▪
circulation of abrasive materials must be
avoided at all costs.
The submersible motor-driven pump must be
▪
protected from frost.
The pump must be protected from running dry.
▪
Access on the part of children should also be
▪
prevented with appropriate measures.
Consistency
Your submersible pump is designed for the
circulation of water with a maximum temperature
of 35° C.
This pump may not be used for other fluids,
especially motor fuels, cleaning fluids,
and other chemical products!
SYMBOLS
Denotes risk of personal
injury or damage to the tool.
Read manual before use.
In accordance with essential
applicable safety standards
of European directives
IPX*
Degree of protection IP
ELECTRICAL SAFETY
Always check that the power
supply corresponds to the
voltage on the rating plate.
Class I
DESCRIPTION
1.
motor housing
2.
water inlet
3.
water outlet
4.
cable & plug
5.
floating switch
6.
carrying handle
7.
build-in floating switch
INSTALLATION
The submersible pump is installed as follows:
In a stationary position with fixed pipeline
▪
or
in a stationary position with a flexible hose pipe.
▪
Please note!
You should never install the pump by
suspending it unsupported from its delivery pipe
or power cable. The submersible pump must be
suspended from the specially provided handle or
be placed on the bottom of the shaft. To guarantee
that the pump works properly, the bottom
of the shaft must be kept free of sludge and dirt of
all kinds.
If the level of water sinks too far, any sludge in the
shaft will dry out quickly and stop the pump
from starting up. Therefore it is necessary to check
the submersible motor pump regularly (by
carrying out start-up tests). The floater is adjusted in
a way that the pump can immediately be started
Mains supply
Your new submersible pump is equipped with a
shock-proof plug according to regulations. The
pump is designed to be connected to a 230 V ~
50 Hz earthed socket. Make sure that the
socket is sufficiently secured (min. 6 Amp.) and is
in excellent condition. Introduce the plug
into the socket and the pump is ready to go.
Important Note!
If the mains cable or plug suffers any damage from
external action, repairs to the cable should
be serviced by a qualified specialist using only
standard spare parts. This will ensure that it
meets the required safety standards.
SETTING TO WORK
After having read these instructions carefully, you
can set your pump to work, reconsidering
the following:
Check if the pump rests on the ground of the
▪
shaft.
Check of pressure cord has been attached
▪
properly.
Check if electrical connection is 230 V - 50 Hz.
▪
Check if socket is in good condition.
▪
Make sure that water and humidity can never
▪
come to the mains supply.
Avoid pump running dry.
▪
12
