ASSIGNING PRESET 1-3

The Connect 5.1 is able to assign presets to three memory keys. All settings in the
speaker and system menu (volume, sound settings, selected input, etc.), as well as
playlists from the app „Spotify" are saved. The memory buttons can be operated
via the Smart-remote as well as via the keypad on the top of the Connect 5.1
Saving inputs and sound settings
In addition to saving playlists from the app „Spotify" (see next page), you can
1
also assign the desired inputs and the selected sound settings to the memory
buttons 1, 2 or 3. For example: Go to the HDMI 1 input and set the volume
level and/or other sound settings to the desired value. To save this input setup
and the specified sound settings, press and hold the memory button 1, 2 or 3 on
the Smart-remote or on the keypad of the Connect 5.1 until the corresponding
number is shown in the LED display and no longer flashes.
To recall the saved input selection and sound settings, briefly press the corre-
2
sponding button 1, 2 or 3. The input and the corresponding sound settings will
then be recalled.
Notes:
• When assigning the 3 memory buttons, you can assign different settings to all
3 memory buttons. Examples:
Memory button 1 = HDMI input 1 & sound setting
Memory button 2 = Favorite Playlist in the app „Spotify" & sound setting
Memory button 3 = HDMI input 2 & sound setting
• When assigning the memory keys, all settings available at the time of saving on
Connect 5.1 (e.g. sound settings, volume, etc.) will be saved.
