cupboard.
2. Selection of the version (extraction or fi ltration)
3. Before starting to fi x the hood, disconnect the anti-grease
fi lter for easier appliance handling:
- Open panel B as shown in Fig.2.
- Pull handle C as shown in Fig.3.
• Fitting the cooker hood into the lower part of the wall
cabinet
For all measurements relating to the cooker hood, please
refer to Fig.4.
Before fi xing the cooker hood to the lower part of the cabinet,
the following steps should be performed:
1- Remove the 4 screws E fi xing the two cooker hood lamps H
(RHS and LHS) in place as indicated in Fig. 5A.
2- Remove the lamps H and disconnect the connectors W of
the halogen lamps to make installation easier, as indicated
in Fig. 5B.
3. Make sure the thickness of the cabinet falls within the range
of values listed in Fig. 5C.
Fit the cooker hood in the cabinet (Fig. 6) and make sure the
4 springs are fi xed in place well.
Fix the cooker hood to the cabinet securely by using a
screwdriver to tighten the screws M until the appliance is
fl ush with the cabinet (Fig. 6).
4. Connect the connectors W of the halogen lamps again and
reinstall the lamps H fi xing them with the 4 screws E that were
previously removed.
• Extractor version
When installed in this way the appliance expels fumes outside,
either through a perimeter wall or through existing ducting.
It is therefore necessary to purchase a non-fl ammable air
exhaust tube (not supplied) which complies with all current
legislation and connect it to fl ange N (Fig.1B).
• Filter hood
Please note:
In order to transform the hood from EXTRACTOR HOOD
into FILTER HOOD the carbon fi lters must be ordered at your
distributor as accessory.
We have two different types of Kit, one with extractable carbon
filters (Fig.7) and the other one with re-usable carbon filters
(washable). (Fig.8)
- To replace the extractable active carbon filters X, pull lever
outwards as shown in Fig.7
- To replace re-usable carbon filters Y, remove the brackets
from their seat, pulling them outwards. (Fig.8)
If you find a bracket such as the one indicated in Fig.9 included
in the product packaging, this should be fixed to the hood
using the supplied screws.

USE AND MAINTENANCE

• We recommend that the cooker hood is switched on before
any food is cooked.
We also recommend that the appliance is left running for
15 minutes after the food is cooked, in order to thoroughly
eliminate all contaminated air.
The eff ective performance of the cooker hood depends on
constant maintenance; the anti-grease fi lter and the active
carbon fi lter both require special attention.
• The anti-grease fi lter is used to trap any grease particles
suspended in the air, therefore is subject to saturation (the
time it takes for the fi lter to become saturated depends on
the way in which the appliance is used).
- To prevent potential fi re hazards, the anti-grease fi lters should
be washed a minimum of every 2 months (it is possible to use
the dishwasher for this task).
- After a few washes, the colour of the fi lters may change. This
does not mean they have to be replaced.
If the replacement and washing instructions are not followed,
the anti-grease fi lters may present a fi re hazard.
• The active carbon fi lters are used to purify the air which is
released back into the room.
The fi lters are not washable or re-usable and must be replaced
at least once every four months.
The active carbon filter saturation level depends on the
frequency with which the appliance is used, the type of
cooking performed and the regularity with which the anti-
grease fi lters are cleaned.
• Clean the cooker hood frequently, both inside and outside,
using a cloth which has been dampened with denatured
alcohol or neutral, non-abrasive liquid detergents.
• The light on the cooker hood is designed for use during
cooking and not for general room illumination.
Extended use of the light reduces the average duration of
the bulb.
• Replacing halogen light bulbs (Fig. 10).
To replace the halogen light bulbs B, remove the glass pane
C using a lever action on the relevant cracks.
Replace the bulbs with new ones of the same type.
Caution: do not touch the light bulb with bare hands.
• Commands: (Fig.11) luminous the key symbols are
explained below:
A = LIGHT
B = OFF
C = SPEED I
D = SPEED II
E = SPEED III
F = AUTOMATIC STOP TIMER - 15 minutes
• If your appliance does not have the INTENSIVE speed
function, press key E for two seconds and it will be activated
for 10 minutes after which it will return to the previously
set speed.
When the function is active the LED fl ashes. To interrupt it
before the 10 minutes have expired press key E again.
• By pressing key F for two seconds (with the hood switched
off ) the "clean air" function is activated. This function switches
the appliance on for ten minutes every hour at the fi rst speed.
As soon as this function is activated the motor starts up at the
fi rst speed for ten minutes, During this time key F and key C
must fl ash at the same time.
After ten minutes the motor switches off and the LED of key
F remains switched on with a fi xed light until the motor starts
up again at the fi rst speed after fi fty minutes and keys F and
C start to fl ash again for ten minutes and so on.
By pressing any key for the exclusion of the hood light the
hood will return immediately to its normal functioning (e.g.
if key D is pressed the "clean air" function is deactivated and
the motor moves to the 2nd speed straight away. By pressing
key B the function is deactivated).
(*) The "automatic stop timer" delays stopping of the
hood, which will continue functioning for 15 minutes at the
operating speed set at the time this function is activated.
- 19 -
