TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 1
TP068
TP Early Fun
Activity Tower
INSTRUCTIONS FOR ASSEMBLY
MAINTENANCE AND USE
Important! These instructions must be followed for safe assembly and
Important! Vous devez suivre ces instructions pour que le montage et
l'utilisation se fassent en toute sécurité. Veuillez conserver pour
Importante! Per garantire sicurezza di montaggio ed uso, seguire
queste istruzioni e conservarle per futuro riferimento.
Importante! Debe seguirse estas instrucciones para un armado y uso
seguros. Sírvase conservarlas para consultarlas en el futuro.
Wichtig! Diese Anweisung ist für sicheren Aufbau und Gebrauch zu
befolgen. Für künftigen Gebrauch aufbewahren.
Importante! Para assegurar uma montagem e uma utilização seguras,
têm de ser seguidas estas instruções. Guardar para referência futura.
WARNING!
use. Please retain for future reference.
référence ultérieure.
™
Important!
Max 45kg
2 yrs - 8 yrs
WARNING!
WARNING!
loading

Verwandte Anleitungen für TP active fun Early Fun TP068

Inhaltszusammenfassung für TP active fun Early Fun TP068

  • Seite 1 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 1 TP068 TP Early Fun ™ Activity Tower INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE WARNING! WARNING! Important! These instructions must be followed for safe assembly and use.
  • Seite 2 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 2 INSTRUCTIONS FOR ASSEMBLY, MAINTENANCE AND USE OF TP TOYS - Please read carefully and keep all enclosed information for future reference. 1.
  • Seite 3 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 3 ISTRUZIONI DI MONTAGGIO, MANUTENZIONE E UTILIZZO DEI GIOCHI TP Leggere attentamente tutte le seguenti informazioni e conservarle per riferimento futuro. 1.
  • Seite 4 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 4 ANLEITUNG ZUR MONTAGE, WARTUNG UND GEBRAUCH VON TP SPIELGERÄT Bitte lesen Sie diese Anleitung vor der Montage und der ersten Benutzung sorgfältig durch. Bitte bewahren Sie diese Anleitung zur Information,bzw.
  • Seite 5 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 5 Unlike steel, wood is a natural, organic material and each piece will be unique, bearing its own knots, cracks and variations in colour and, unlike steel, wood will react significantly to changes in atmospheric conditions.
  • Seite 6 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 6 Tools - You will need: Early fun™ activity tower TP068 Vous aurez besoin de: Sie benötigen: Siete Pregati di Controllare il Contenuto Avrete bisngno: Verifique El Contenido Contents - Please check...
  • Seite 7 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 7 Components PM2005 MW1298 Step Climbing Board MW1295 Climbing Wall Support 10° Corner bracket MW1294 Deck Board Support PM2019 Swing leg foot MW1297 Bottom Climbing Board MW1052...
  • Seite 8 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 8 PM2005 M8 Washer M8 Dome 10° Corner bracket M8 x 120 (17mm o/dia) lock nut MW1291 Swing Arm M6 Mudguard M6 Dome M6 x 65 Washer...
  • Seite 9 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 9 PM2019 Swing leg foot MW1294 Deck Board Support M4 x 50mm Woodscrew MW1293 Sides 20mm 40mm 40mm TP early fun™ activity tower...
  • Seite 10 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 10 M4 x 50mm Woodscrew MW1299 Deck Board MW1199 Deck Board MW1299 MW1299 MW1299 MW1299 MW1299 13mm Upper Platform MW1199 MW1299 MW1299 MW1299...
  • Seite 11 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 11 FA8445 M8 Washer M8 x 80mm MW1286 Mid RH Upright MW1287 Mid LH Upright MW1288 Rear RH Upright MW1289 Rear LH Upright MW1286 MW1288...
  • Seite 12 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 12 FA8445 MW1284 FNT RH Upright M8 x 80mm M8 Washer MW1285 FNT LH Upright MW1284 MW1285 575mm Drill 3mm Pilot Holes TP early fun™...
  • Seite 13 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 13 M6 Dome MW1293 Sides lock nut M6 Mudguard M6 x 60mm Washer M8 Washer FA8445 M8 x 80mm PM2025 1165mm 120mm 120mm...
  • Seite 14 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 14 M8 Dome M8 Washer lock nut M8 x 80mm M8 x 120mm TP early fun™ activity tower...
  • Seite 15 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 15 M8 Washer MW1290 Climbing Wall Leg M8 x 110mm PM2019 M6 Mudguard M8 Dome M6 Dome Swing leg foot Washer lock nut lock nut...
  • Seite 16 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 16 M4 x 50mm Woodscrew MW1295 Climbing Wall Support 15mm 20mm TP early fun™ activity tower...
  • Seite 17 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 17 M4 x 50mm Woodscrew MW1297 Bottom Climbing Board MW1298 Step Climbing Board MW1297 MW1298 MW1298 MW1298 MW1298 MW1298 15mm TP early fun™...
  • Seite 18 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 18 MW1431 Blackboard Support MW1052 Climbing Wall Support M4 x 50mm Woodscrew 50mm MW1052 MW1431 50mm MW1431 TP early fun™ activity tower...
  • Seite 19 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 19 MT0019 Climbing Rung M6 Washer M6 x 35mm Woodscrew FC9943 Blackboard M4 x 25mm Woodscrew PM2038 Green Plastic Cup Washer 80mm TP early fun™...
  • Seite 20 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 20 M8 Washer MT0019 Climbing Rung M8 x 35mm 200mm 200mm TP early fun™ activity tower...
  • Seite 21 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 21 PM2038 Green Plastic Cup Washer M4 x 15mm Woodscrew FB3008 Side Fabric Panel FB3009 Rear Fabric Panel 20 Fixings 24 Fixings 125mm 150mm...
  • Seite 22 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 22 PE8280 Canopy White Plastic Tube FB3010 Canopy Fabric Panel TP early fun™ activity tower...
  • Seite 23 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 23 PV9589 1.2m Slide M4 x 40mm Woodscrew PM2038 Green Plastic Cup Washer M5 Dome M5 Washer lock nut M5 x 40mm Bolt PR8971 No.8 x 12mm Branding badge...
  • Seite 24 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 24 M6 Mudguard M6 Dome M8 Dome M8 x 155mm Washer lock nut lock nut Hook bolt M6 x 65 PM 8312 M8 Washer 32mm...
  • Seite 25 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 25 Recommended ground fixing 45˚ 45˚ Cement ground peg into position. l Set the stakes in concrete (as shown). l Never set the legs of the frame in concrete. l Fixez les poteaux dans le bèton comme cela est montrè.
  • Seite 26 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 26 Recommended Free Space: The Safe Play Area refers to the zone extending 200cm beyond the toy on all sides, including the space above the toy. The Safe Play Area must be free from all structures, landscaping, trees and branches, rocks, wires, sprinkler heads and other similar obstacles to safe play.
  • Seite 27 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 27 Register your new TP product on-line now at Product Registration Form www.tptoys.com/productregistration Miss For a chance to win £200 of TP products in our next quarterly on-line guarantee registration draw.
  • Seite 28 TP068 - Activity Tower Inst 6067 Issue-B 02 10:TP068 - Activity Tower Inst 6067 Issue-B 02 10 25/02/2010 11:30 Page 28 Please note this guarantee applies only to the original purchaser of this TP product, and is applicable only when the play frame is in standard domestic family use. Thank you for purchasing this TP early fun™...
