Minilux

Project planning

Minilux Control lux setting
Calculation form
Documentation of Minilux Control settings
Project
No.
Location
Date
Lux range:
+
Measurement of indoor lighting
(without artificial light) "Lx ind"
Lx ind
Luxmeter
Lux value at light
sensor "Sensor"
Required light level
"Setp"
Setp
Servodan A/S | Tel +45 7442 4726 | Fax + 45 7442 4035 | info@servodan.dk | www.servodan.com
R0
3-300 Lux 30-3.000 Lux
Lx ind _________ Lux
:
Note! The lux value at the light sensor must be measured at the
same daylight conditions as the above measurement of indoor
lighting.
See Lux value at the light sensor in Minilux Control display.
Sensor: _______ Lux
Lux on setting
Setp:_________ Lux
Lux on is set on the Minilux Control:
(
Sensor
Lux on = Setp x
Lx ind
Example:
( )
4000
Lux on = 400 x = 8000 Lux
200
Minilux Control type
Minilux Sensor type
Application Indoor
300-30.000 Lux
)
36-0 80
43-19 _
Outdoor
