NO. PART NO. DESCRIPTION
1 QA-315P01 Motor Housing
2 QA-315P02 Throttle Bushing
3 QA-315P03 O-Ring
4 QA-315P04 Valve Stem
5 QA-315P05 O-Ring
6 QA-315P06 Spring
7 QA-315P07 Regulator
8 QA-315P08 O-Ring
9 QA-315P09 O-Ring
10 QA-315P10 Throttle Valve Plug
11 QA-315P11 Throttle Lever
12 QA-315P12 Spring Pin
13 QA-315P13 Exhaust Plate
14 QA-315P14 O-Ring
15 QA-315P15 Air Inlet Bushing
16 QA-315P16 Ball Bearing
17 --- Rear End Plate
18 --- Spring Pin
19 QA-315P19 Cylinder
20 QA-315P20 Rotor
21 QA-315T21 Rotor Blade (4pcs) 1 Set
22 QA-315P22 Rotor Collar
23 --- Front End Plate
24 --- Steel Ball
25 QA-315P25 Ball Bearing
26 --- Clamp Nut
27 QA-315P27 Motor Clamp
28 QA-315P28 Coupling
QA-315
Q'TY NO. PART NO.
1 29 ---
1 30 ---
1 31 ---
1 32 ---
1 33 ---
1 34 ---
1 35A1 QA-315P35A1 Collet 3 mm
1 35A2 QA-315P35A2 Collet 6 mm
1 35B1 QA-315P35B1 Collet 1/8"
1 35B2 QA-315P35B2 Collet 1/4"
1 36 QA-315P36
1 37 QA-315P37
1
40 QA-315P39
1
1
41 QA-315P40
1
42 ---
1
1
QA-315T01
1
1 QA-315T02
QA-315T03
1
1
1
1
1
1
1
DESCRIPTION
Ball Bearing
Clamp Nut
5" Extension Housing
Spindle
Ball Bearing
Collet Sleeve
Collet Nut
Grip
17 mm
Spanner Wrench
11 mm
Spanner Wrench
Steel Ball
Rear End
Plate Ass'y (17.18)
Front End
Plate Ass'y (23.24.42)
5" Extension Housing
Ass'y (26.29~34)
Q'TY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 Set
1 Set
1 Set
