Product Characteristics for U2600A Series DIO Modules

REMOTE INTERFACE
• USB 2.0 High Speed
• USBTMC Class Device
POWER REQUIREMENT
• +12 VDC (Typical)
• 2 A (maximum) input rated current
• Installation Category II
POWER CONSUMPTION
• +12 VDC, 260 mA (maximum)
OPERATING ENVIRONMENT
• Operating temperature from 0 °C to +55 °C
• Relative humidity at 15% to 85% RH (non-condensing)
• Altitude up to 2000 meters
• Pollution Degree 2
• For indoor use only
STORAGE COMPLIANCE
• –20 °C to +70 °C
SAFETY COMPLIANCE
Certified with:
• IEC 61010-1:2001/EN 61010-1:2001
• Canada: CAN/CSA-C22.2 No.61010-1-04
• USA: ANSI/UL 61010-1: 2004
EMC COMPLIANCE
• IEC 61326-1:2002/EN 61326-1:1997+A1:1998+A2:2001+A3:2003
• CISPR 11: 1990/EN55011:1990 – Group 1 Class A
• Canada: ICES-001: 2004
• Australia/New Zealand: AS/NZS CISPR11:2004
SHOCK & VIBRATION
• Tested to IEC/EN 60068-2
IO CONNECTOR
• 100-pin SCSI-II connector
DIMENSION (WxDxH)
• 120.00 mm x 182.40 mm x 44.00 mm (with plastic casing)
• 105.00 mm x 174.54 mm x 25.00 mm (without plastic casing)
WEIGHT
• 535 g (with plastic casing)
• 370 g (without plastic casing)
WARRANTY
• 3 years
U2600A Quick Start Guide 5
