5. Lens Adjustment
I. Adjust the lens to the desired position.
II. Focus
1) Loosen the lens lock screw.
2) Remove the lens hood.
3) Rotate the lens until the image in the Live View page is focused.
4) Retighten the lens screw lock.
5) Reattach the lens hood.
WARNING - Do not over rotate the lens.
6. Complete the Installation
Place the dome cover back on the camera device using the supplied Allen Key.
Lens Lock Screw
