Technical Specification

Table 1
Power Supply
Input Voltage
Input Frequency
Input Power
Protection Fuse
Operating Temperature
Storage Temperature
Installation Category
Pollution Degree
A rotary selector that permits the following settings is provided for
baud rate selection:
Table 2
Selection
0
1
2
3
4
5
6
7
8
9 to F
Protocol Converter RS232-485 User Manual / 87-900-974-01 (E)
Procedure for Installation of the RS232 - RS485 Protocol Converter
Technical Specification
Technical Information
100 – 240 Vac
50 – 60 Hz
30 VA
2 A (Line type)
+5° C to 45° C
-20° C to 70° C
II
2
Baud Rate
110
300
1200
2400
4800
9600
19200
38400
57600
115200
18
