This paragraph details the fundamental operating procedures. Make
all electrical connections before the use of the system.
Switching on and Use of Protocol Converter
At switch on the POWER green led light on. After a network
connection the Protocol Converter starts to convert RS232 signals in
RS485 signals and viceversa. There are other light indicators to
understand the device behaviour:
Protocol Converter Switching off
To switch off the Protocol Converter it is necessary to remove the
mains. The integrated controller immediately stops the pump.
WARNING!
The Turbo-V controller must be powered with 3-wire power cord (see
orderable parts table) and plug (internationally approved) for user's safety.
Use this power cord and plug in conjunction with a properly grounded power
socket to avoid electrical shock and to satisfy CE requirements . High voltage
developed in the controller can cause severe injury or death. Before servicing
the unit, disconnect the input power cable.
Protocol Converter RS232-485 User Manual / 87-900-974-01 (E)
ERROR led : indicates that there is an error in the received frame
RS232 led: indicates data traffic on RS232 port
RS485 led: indicates data traffic on RS485 port
Fiber led: indicates data traffic on fiber optic port.
Instructions for Use
