Tyco WS9TCHW Installationsanleitung Seite 2

Requirements and Specifications
Environmental Requirements
Installation type :Indoor,non-hazardous locations.
This module is to be installed by service persons only.
This product is RoHS compliant.
WS9TCHW Specifications
Screen type :Capacitive touch
Viewing angle:Right:60,Left:60,Up:60,Down:60 degrees
Power Specifications
AC:Plug-in transformer Class 6 for North America
External power manufacturer: Helms-Man Transformers Company ltd.
External power rated technical parameters:
Input:100 - 240 V~ 50 -60 Hz mA
Output:5 V - 2000 mA
Note: USB port is for AC power and battery charging only. Do not connect to PC for
communication.
Unit Specifications
Operating temperature: 0 °C to 45 °C
Operating humidity: 5% to 93% RH,non-condensing
Camera: 2 megapixels
Other Specifications
SAR testdistance: 5 mm.
Max SAR:0.51 W/Kg
Frequency range:2412 MHz to 2462 MHz for US;2412 MHz to 2472 MHz for EU
RF Outputpower:16 dBm maximum
