Manual Operation mode
The AVSPLIT-27can be used manually; the "SELECT" button is used as power
button and manual switch.
To power-on or power-off the AVSPLIT-27, please press the "SELECT" button for 3
seconds. Press the "SELECT" button once to select the inputs. The LED will indicate
which input is current source device. If you select Input 1, the "IN1" LED will light on.
The procedure is a cyclic function.
Front Panel
Rear Panel
Read Panel
Front Panel
ILLUSTRATION
CONNECTION ILLUSTRATION
Home Theter
System
2
DVD player/
Blue-ray
DC Adaptor
