Avtek Speaker
User manual
Note! Please check to make sure the amplifier in use matches the speaker's power before
connecting the device

Assembly steps

1. Fix the bracket into position as follows .
1. expansion tube
2. positioning screw
3. bracket plate
2. Fix one end of safety cable to the bracket plate, fix
the other end to speaker using M6 Cross crews
M6. Then hang the speaker onto bracket plate as
follows.
1. hand bolt
2. speaker
2
1. hand screw bolt
2. speaker cabinet
3. speaker Braket
