Information For Operation - Würth MINI Originalbetriebsanleitung

Operating modes:
• upright, to a tilt angle of 90°
• horizontal (with upward light emission)
• suspended (mounted on a hook or a tripod).
Attention!
In case of exposure to splash water connect the device only to IPX4 sockets!
Art.
0981 180 020, 0981 180 021,
0981 180 301
0981 180 501, 0981 180 511,
0981 180 502, 0981 180 512
Attention!
If your lamp is equipped with a plug, it is not admissible to mount the device
on a tripod with an angle exceeding 90° if exposed to splash water! Maxi-
mum mounting height may not be exceeded!
Item no. 0981 180 900, 0981 180 910:
Art. 0981 180 901
Art.
0981 180 900 / 0981 180 910 One or two lamps mountable with mounting rail

Information for operation

Mounting on a tripod
No tripod mounting possible
One or two lamps mountable with mounting rail
Item no. 0981 180 591 on tripod item no. 0981 100 1/0981 101 1
Accessories:
Mounting bracket with integrated cable rewind
Mounting on a tripod in combination with Art. 0981 180 901
item no. 0981 150 5 on tripod item no. 0981 100 1, 0981 101 1
230 V / 25 W =
max. 30 x (5 m H07BQ-F 3G1.5 mm )
2
11
