Maintenance
■ Cleaning the unit
Periodically wipe the unit with a clean soft cloth.
Caution:
●
Do not use chemicals for cleaning (petrol, paint thinner, etc.).
It may damage the unit finishing.
●
Do not apply oil to the inside of the unit. It may cause
malfunctions.
Specifications
As part of our policy of continuous improvement, SHARP
reserves the right to make design and specification changes for
product improvement without prior notice. The performance
specification figures indicated are nominal values of production
units. There may be some deviations from these values in
individual units.
■ General
Power source
DC IN 6V
(AC 100 - 240 V ~ 50/60 Hz)
DC IN 6V
R6 or HP-7) battery x 4]
Power
Power On: 7 W
Power Stand-by: 0.6 W (*)
consumption
Output power
Front speakers:
RMS: 2.4 W (1.2 W + 1.2 W) (10%
T.H.D.)
RMS: 0.72 W (0.36 W + 0.36 W) (1%
T.H.D.)
Subwoofer:
RMS: 2 W (10% T.H.D.)
RMS: 0.81 W (1% T.H.D.)
2A: AC/DC adaptor
[ "AA" size (UM/SUM-3,
Speaker
2.1-way type speaker system
Front speaker: 3.0 cm (1-1/8")
Subwoofer: 4.6 cm (1-3/4")
Speaker maximum
Front speaker: 2.0 W/Channel
Subwoofer: 4 W
input power
Speaker rated
Front speaker: 1.2 W/Channel
input power
Subwoofer: 2 W
Output terminals
Video output: 1Vp-p
Input terminals
Auxiliary (audio signal):
250 mV/47 k ohms
Dimensions
Width: 208 mm (8-3/16")
Height: 69.8 mm (2-3/4")
Depth: 83 mm (3-1/4")
Weight
0.72 kg (1.58 lbs.)
(*) This power consumption value is obtained when in the power
stand-by mode.
DK-AP8P
ENGLISH
E-14
