5
FA 5193
4
Minimum distance between the suspension points of a swing measured along the crossbeam shall be
calculated as follows A = 0,04 h + B where:
A is the distance between the suspension points along the crossbeam;
B is the distance between the junction points of the swing element and the means of suspension;
h is the distance from the ground to the lower side of the crossbeam.
TP933 Pirate Boat PN9397 Issue-G 03 18.indd 10
FC 8519
PM5243
4 4
350mm min.
8
10
10
Fitting To TP Swing Frames
Montage sur balançoires TP
Montage an TP-Schaukeln
Montaggio sulle altalene TP
Instalación en columpios TP
Bolt Tightening Guide
Pirate Boat
