3. If the Routing 2 is selected, these Messages are recognized to conrol Routing
Parameters.
Faders and PanPots are assigned to each effect modules( E1
-
E4
)
by MIDI
Channel
s.
The
MIDI
Channel Settings are following:
Fader/PanPot to
channel 1 E1 Mix Level
/
Pan
channel 2 E2 Mix Level
/
Pan
channel 3 E3 Mix Level
/
Pan
channel 4 E4 Mix Level
/
Pan
channel 5 E1 Send Level
/
Pan
channel 6 E2 Send Level
/
Pan
channel 7 E3 Send Level
/
Pan
channel 8
E4
Send Level
/
Pan
Value vvvvvvv for Fader is O:min, 127:max.
Value vvvvvvv for PanPot is
;
Left
<-
Center
->
Right
0 6 4 127
4. Assignment of Bank No.
;
OOOOH - Interna1 Memory
OOOlH
-
Card System 1
0002H
-
Card System 2
0003H
-
Card System 3
3FFFH
-
Preset Patches
Program Changes will be done in current Bank which is selected by last Bank
Select Message from
MIDI.
5. Bypass function is always recognized in BASIC Channel.
Value vvvvvvv is 0, Bypass is turned off.
Value vvvvvvv is 127, Bypass is turned on.
2) NRPN
STATUS SECOND TH
I
RD DESCRIPTION
1011 nnnn 0000 0110 Ohhh hhhh
MSB
,of DATA ENTRY
hhh hhhh : Parameter value of MSB (See Note 1)
1011 nnnn 0010 0110 0111 1111 LSB of DATA ENTRY
1 1 1 1111
:
Paramter Value of LSB (See Note 1)
1011 nnnn 0110 0000 Oxxx xxxx DATA INCREMENT
xxx
xxxx
will be ignored
