TP active fun TP037 Anleitung Zur Montage, Wartung Und Gebrauch Seite 10

TP037 Early Fun Swing IN9557 -E 07 17.qxp_TP037 Early Fun Swing IN9557 -E 07 17 03/07/2017 15:06 Page 10
4A
4 B
FC8392 1132mm (Green)
8
FC8519
C
2
FC8394 921mm (Yellow)
M6 x 58mm M6 x 35mm
Low Height Assembly
4 4
Montage à faible hauteur
FA8418 FA8416
Montaggio per l'altezza più bassa
Montaje bajo
Halbhohe Montage
Montagem a altura baixa
A
35mm
35mm
B
58mm
58mm
C
58mm
58mm
TP Early Fun Swing
10
