1. Adjustable headband
Allows you to adjust the headset for a snug fit.
2. Ear cups
Provides you with an enhanced audio experience.
3. Microphone
Storable and adjustable microphone for two-way communication.
4. Cable management system
Allows you to easily fold and secure the cable for tangle-free storage.
5. Gaming/FPS button
Press the Gaming/FPS button to enable/disable the FPS EQ mode.
6. Surround button
Press the Surround button to enable/disable the surround sound.
7. Amp button
Press the Amp button to enable/disable the headphone amplifier.
8. Microphone jack (Red)
Insert a microphone plug to this port.
9. Headphone jack (Green)
Insert a headphone plug to this port.
10. Headphone plug
Allows you to connect to the headphone port of your computer or
the USB dongle.
11. Microphone plug
Allows you to connect to the microphone port of your computer or
the USB dongle.
12.In-line clip
Allows you to clip the in-line volume control to your clothes.
13.Volume control
Allows you to increase/decrease the volume.
14. Mute control
Allows you to put the microphone on mute mode.
