This quickstart guide provides basic instructions for setting up and using your XRS Stick Reader. For more detailed instructions, see the
XRS Stick Reader User Manual
comprehensive
Note:
In this document, EID = Electronic Identification and VID = Visual Identification.
Before you start
Charging the internal battery
Note: Before using the stick reader, ensure that the internal battery is fully charged. The battery will be fully charged in approximately 3 hours.
When fully charged, the internal battery will allow the stick reader to be used for up to 19 hours
The stick reader may be used while it is on charge.
For other battery charging options, see the
Using EziLink TM
EziLink software can be installed from the CD provided with the XRS Stick Reader. EziLink allows information to be transferred to and from the
stick reader and a PC. A number of stick reader settings can be adjusted on the stick reader itself, but there are some that must be configured
using EziLink.
To use EziLink:
1 Install the EziLink software on a PC (see information
provided on the EziLink CD).
2 Connect the stick reader to the PC's USB port using the
XRS-Serial cable and the USB-Serial adaptor (see
opposite).
3 Launch EziLink by double-clicking on the EziLink icon on
the desktop:
When connected, the XRS icon in the top right-hand
corner of the EziLink screen illuminates and the
connection details appear at the bottom of the screen.
Note:
For troubleshooting information, see the information
provided on the EziLink CD.
When default settings are used.
1
available on the CD supplied or at www.tru-test.com.
XRS Stick Reader User Manual
.
.
1
© Tru-Test Limited, 2011 All rights reserved
Bluetooth®
is a registered trade mark owned by Bluetooth SIG, Inc.
813557 issue 2, 10/2011
