4. Basic connections

4-1. Connecting the recorder in the LAN

Use a Category 5e or higher LAN cable (straight cable).
INR-Q500
IPD-Q01P
IPD-Q01P
IPD-Q01P
IPD-Q01P
HUB
LAN cable (straight cable)
PC
Connecting the LAN cable
INR : 192.168.1.200
LAN cable (straight cable)
PC : 192.168.1.10
E-4
Example (INR-Q500)
IP IP address ： 192.168.1.200
Subnet mask ： 255.255.255.0
User name ： ［admin］
Password ： 1
Use a hub with gigabit (1000M) ports.
Connect the INR-Q500 to the gigabit-
compatible port.
Example (PC)
IP IP address ： 192.168.1.10
Subnet mask ： 255.255.255.0
