TP active fun TP843 Anleitung Zur Montage, Wartung Und Gebrauch Seite 9

TP843 Explorer Frame Set Inst 5012 -B 10 15.qxp_TP843 Explorer Frame Set Inst 5012-B 10 15 19/10/2015 11:38 Page 9
6
MT0336
Fix using top
holes
Fix using
bottom holes
x2
712mm
TP845
Platform
x1
9 7
FA3839M FA3839F
M6 x 12mm inc Spring Washer
x4
M8 x 24mm
x4
MT0336
MT0336
Fix using top
holes
TP Explorer Climbing Set with Platform & Den
