TP active fun TP843 Anleitung Zur Montage, Wartung Und Gebrauch Seite 6

TP843 Explorer Frame Set Inst 5012 -B 10 15.qxp_TP843 Explorer Frame Set Inst 5012-B 10 15 19/10/2015 11:37 Page 6
1
FA3839
Washer
x1
FA2839F FA2839M FA7151
M10 x 13mm M8 x 10mm Spring
x1 x1
Washer
x1
x3
MT0332
6
Assembly
Montage
Montaggio
Montaje
Montage
TP Explorer Climbing Set with Platform & Den
