1. DESCRIPTION
2. CONNECTIONS
Connect the red cable of the battery's "+" terminal (red terminal) with the inverter's
"+" binding post (red connection) and the black cable of the battery's "-" terminal
(black terminal) with the inverter's "-" binding post (black connection). The cable is
≤ 2m.
Be sure to tighten the screws in order to avoid loose connection.
3. FUSE
Please check the fuse on the cable if the blackout indicator is not lit during
operation. Replace a blown fuse with an identical one. Please refer to "14.
SPECIFICATIONS".
