W7002 Series: W7152, W7152P, W7172, and W7252 Cordless Impact Wrench - Parts List
Item
Part Description
1
LED Kit
Hammer Case Kit for W71 52,
W7152P and W7252
1
LED Assembly
2
Hammer Case Assembly
3
Washer
Hammer Case Kit for W7172
1
LED Assembly
4
Hammer Case Assembly
Anvil Kit for W7152
5
1/2" Anvil, Retaining Ring
6
O-Ring
7
Retaining Ring
Anvil Kit for W7252
8
1/2" Anvil, 2" Extended
6
O-Ring
7
Retaining Ring
Anvil Kit for W7152P
9
1/2" Anvil, Pin
10
Retaining Pin
11
Spring
Anvil Kit for W7172
12
3/4" Anvil
13
O-Ring
14
Retaining Ring
Socket Retainer Kit
for W7152 and W7252
6
O-Ring
7
Retaining Ring
Socket Retainer Kit for W7152P 2125PTi-K425
10
Retaining Pin
11
Spring
Socket Retainer Kit for W7172
13
O-Ring
14
Retaining Ring
15
Impact Mechanism Kit
Gear Kit
16
Planet Gear (QTY. 3)
17
Gear Pin (QTY. 3)
18
Cam Thrust Washer
19
Brushless Motor Kit
2
Part Number
(CCN)
W7152-KLED
(47631609001)
W7152-K727
(47631602001)
---
---
---
---
---
---
W7172-K727 (47663576001)
---
---
---
---
W7152-K626 (47631603001)
---
---
---
---
---
---
W7252-K626
(47633585001)
---
---
---
---
---
---
W7152P-K626 (47631604001)
---
---
---
---
---
---
W7172-K626 (47663577001)
---
---
---
---
---
---
2125QTi-K425
(80107733)
---
---
---
---
(80107725)
---
---
---
---
2145-K425
(47118112)
---
---
---
---
W7152-K724 (47631605001)
W7152-K37
(47631606001)
---
---
---
---
---
---
W7152-K54
(47631607001)
Item
Part Description
20
Insulator Sheet Kit
Drive Kit
21
Drive Assembly
31
Information Label
23
Directional Switch Kit
24
Regulator Kit
25
Backcap Kit
Fastener Kit
22
Screw, Hall PCBA (QTY. 4)
26
Screw, Hammercase
(QTY. 4)
27
Screw, Housing (QTY. 7)
Housing Kit
28
Left Housing
29
Right Housing
30
Warning Label
27
Screw, Housing (QTY. 7)
Label Kit
30
Warning Label
31
Information Label
32
Hanger Kit
Backcap
Screw, Hammercase
(QTY. 2)
Screw, Long Hammercase
(QTY. 2)
Ring
Bracket
33
Battery, BL2022
Battery Charger
*
Protective Tool Boot
*
Power Regulator Restricted
*
Tool Boot
Protective Battery Boot
*
Tool Bag
*
Grease
*
IR #105 (1 LB Can)
IR #105 (8 LB Can)
IR #67 (1 LB Can)
IR #67 (8 LB Can)
Grease Gun
*
* Indicates not illustrated.
Part Number
(CCN)
W7152-K624 (47633589001)
W7152-K93
(47631611001)
---
---
---
---
W7152-K75
(47631610001)
W7152-K249 (47631608001)
W7152-K40B (47631613001)
W7152-K105 (47631614001)
---
---
---
---
---
---
W7152-K40
(47631612001)
---
---
---
---
---
---
---
---
W7152-K99
(47631615001)
---
---
---
---
W7152-K365B (47632290001)
---
---
---
---
---
---
---
---
---
---
BL2022
(47515902001)
BC1121
(47507879001)
W7152-BOOT (47621732001)
W7152-BOOTX (47621734001)
BL2010-BOOT (47510964001)
TB4
(47543666001)
105 1 LB
(04279147)
105 8 LB
(04264875)
67 1 LB
(03773009)
67 8 LB
(03820008)
R000A2-228
(03095015)
47631618001_ed4
