Know your product

1. Dual Laser light assembly
2. Dual Laser light on/off button
3. Dual Laser light aperture
4. Trigger switch
5. Lock-off button
6. Motor housing
GB
7. Main handle
8. Front handle
9. Bevel adjustment knob
10. Bevel scale
11. Parallel fence locking knob
12. Parallel fence
13. Blade guard lever
14. Lower blade guard
15. Base plate
16. Upper blade guard
17. Dust extraction port
18. Depth locking lever
19. Depth of cut indicator
20. Spindle lock button
21. Blade
22. Blade wrench
23. Blade guide notch
24. Parallel fence slots
25. Disc rotation indicator
DLS2000MCF_IM.indd 8
22
12
17
16
13
21
20
14
6
8
8
5
4
19
7
18
15
2
1
3
25
10
11
9
24
23
