Before You Begin

Determine which interface to use
Select a TV interface based on the particular hole pattern of your TV. DO NOT begin installation yet, only determine which interface to
use.
A. Use the smaller interface [04] for 75 - 200 mm hole patterns.
B. Use the larger interface [01, 02, 05] for hole patterns between 200 and 400 mm, and up to 450 mm wide.
A
B
6903-002010 <02>
[04]
OR
[02]
400 mm
(16 in.)
[05]
[01]
[02]
400 mm
(16 in.)
5
