Parts - Cosmo DC16ET Bedienungsanleitung

Part no. Part name
A. Plastic parts
101 FRONT PLATE
102 REAR PLATE
103 CONTROL PANEL FOR
ELECTRONIC TYPE
105 WIND BAFFLE
106 BACK-LIGHT SLOT
107 AIR INLET FRAME
108A FILTER FRAME
108B FIXER FOR FILTER
109 LCD MONITOR
110L TOUCH BUTTON (LEFT)
110R TOUCH BUTTON (RIGHT)
111 WATER TANK
112 WATER TANK COVER
114 FLOAT
115 BUOY
116 BOTTOM BASE
117 FAN BLADE
118 MIDDLE SPACER
119 WIND FUNNEL
120 RUBBER STOPPER
Q'ty Part no.
pc/set A. Plastic parts
1 121
1 123
124
1
B. Electric parts
1
201
1
201A
1
201B
1
201C
1
201D
1
201E
1
202A
1
202B
1
202D
1
203
1
204
1
205A
1
205B
1
206
1
207
1
211
1
217

11. PARTS

Part name
CASTERS
TOP COVER FOR SENSOR
BOTOM COVER FOR SENSOR
COMPRESSOR
OVERLOAD PROTECTOR
WIRE CONNECTING BOX
ANTI-VIBRATION SOCKET
RUBBER GROMMET
CLIP
MOTOR
MOTOR CAPACITOR
MOTOR WASHER
POWER CORD
CAPACITOR FOR COMPRESSOR
MAIN P.C. BOARD
LCD DISPLAY BOARD
MAGNET
MAGNETIC SWITCH
TERMINAL SOCKET
UV LIGHT
21
Q'ty
pc/set
4
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
