The spec label (*)
1
4
The spec label illustration may be different
from the actual label used.
(*) Label is located at the bottom of the unit.

■ Bottom view

1. Battery Compartment . . . . . . . . . . . . . . . . . . . . . . . . . 6

■ Rear panel

1. FM Aerial Wire (fixed) . . . . . . . . . . . . . . . . . . . . . . . . 14
2. DC Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. Audio In Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4. Video Out Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 3
DK-CL8PH
1
The iPod rating mark
1A
Reference page
Reference page
ENGLISH
E-4
