TV Adjustments

TILT ADJUSTMENT

Your TV should adjust easily when moved, then stay in place.
If your TV is too loose or too tight, adjust the tilt tension knob by hand.
NOTE: Once your TV is in place, tighten the tilt tension knob to
prevent unwanted movement.
16
Tilt Tension Knob K b

LEVEL ADJUSTMENT

To adjust the leveling of your TV, loosen the locking screw
your TV, then tighten locking screw
IMPORTANT: This locking screw
the TV onto the wall plate assembly
18
, level
22
.
22
must be installed to secure
22
.
18
22
