GB
REMOVE AND DISCARD
THE YELLOW TRANSIT
!
TAG BEFORE USING THIS
PRODUCT
Fast Cart
2450
TOOLS REQUIRED
Pozi (cross head) screwdriver
CONTENTS (Fig.1)
A. Fast Cart
- 40m 1/2" (13mm)
or
- 30m 5/8" (16mm)
B. Hose end connector x 2
C. Water stop connector
D. Nozzle
E. Feeder hose 1/2''
or
E. Feeder hose 5/8''
F. End plug
G. Handle sleeve
H. Threaded tap connector
I.
Steel tube x 2
J. Pull along handle
K. Accessory rack
L. Handle trim
M. Screw 38mm long x 4
N. Screw 19mm long x 2
ASSEMBLY
Remove all components from their
packaging and proceed as follows:
Fig.2 - Locate one of the steel
tubes (I) in to one of the holes in
the handle (J). Rotate the tube to
align the screw holes, and insert
38mm screw (M). Repeat the
procedure for the second tube.
Fig.3 - Locate the accessory rack (K)
over the 2 steel tubes as shown,
and secure to the handle using the
two 19mm screws (N).
Fig.4 - Ensure Fast Cart logo is to
the front (as shown), locate
Handle Trim (L) onto the metal
tubes.
Fig.5 - Ensure the orientation of
the handle assembly is correct (as
shown) align the two tubes into
the casing, and secure using the
two remaining 38mm screws (M).
Fig.6 - Locate the handle sleeve (G)
into the winding handle and snap
into position, secure the sleeve
using the end plug (F) then attach
the STOP connector (C) to the end
of the hose. Locate handle trim (L)
onto the casing and clip into
position.
Fig.7 - Attach a connector (B) to
both ends of the feeder hose (E),
and snap on to inlet of hose cart.
the feeder hose is stored on the
handle of the Fast Cart.
Fig.8 - Attach the nozzle (D) to the
STOP connector (C), already fitted,
then connect the feeder hose to
your tap, using threaded tap
connectors, with or without the
white adaptor (H).
Fig.9 - When rewinding, ensure
™
the hose cart is aligned with the
hose.
WATER INLET HOSE
If the water inlet hose supplied is
too short to reach your tap,
replace it with any good quality
hose.
PRODUCT USE
This cart is designed for external
use only, and is not suitable for use
indoors.
If the hose is to be used around
corners, Hozelock recommends the
use of a hose guide, part number
2392, which is not supplied.
Before using the Fast Cart for the
first time, unwind all the hose,
open the hose end nozzle and run
water through it.
IMPORTANT
If the hose does not rewind fully
when the tap is on, turn off the
tap and open the hose end
nozzle to depressurize the hose,
then rewind.
This hose cart is fitted with a
drum lock that stops the hose
unwinding when the product is
being moved. Do not attempt
to unwind the hose unless the
hose cart is stationary and
upright, and flat onto the floor.
To prevent damage:
Do
Store the cart inside in winter to
prevent frost damage.
Turn the tap off when not in use.
Frequently check the hose end
fitting is secure.
Do Not!
Wind the hose in without a ball
stop or hose end connector fitted.
Take the main casing apart.
Wind the handle in the opposite
direction to the arrow.
HOSE REPLACEMENT
If the hose becomes damaged, do
not attempt to repair it. Contact
Hozelock consumer Services for a
replacement kit and instructions.
Replacement kit part number:
For 1/2" (13mm) hose - Z 21920
For 5/8" (16mm) hose - Z 21921
ADVICE AND SPARES
For product advice and spares,
please contact:
Hozelock Consumer Services,
Haddenham,
Aylesbury,
Bucks,
HP17 8JD
Tel: 01844 292 002
GUARANTEE
This Cart is guaranteed for 2 years
against faults arising from
defective manufacture or
materials.
Please keep your purchase receipt.
F
RETIRER ET DISPOSER DE
L'ETIQUETTE DE TRANSIT
!
JAUNE AVANT D'UTILISER
CE PRODUIT
Fast Cart
2450
OUTILS NECESSAIRE
Tournevis à pointe cruciforme
renforcée
CONTENU (Fig.1)
A. Dévidoir Fast Cart
- 40m (13mm)
ou
- 30m (16mm)
B. Raccord de fin de tuyau x 2
C. Raccord Stop
D. Lance d'arrosage
E. Tuyau d'alimentation en eau
13mm
ou
E. Tuyau d'alimentation en eau 16
mm
F. Embout
G. Manchon de manivelle
H. Raccord pour robinets filetés
I. Tube en acier x 2
J. Anse de 'tractage'
K. Porte accessoires
L. Moulure pour anse
M. Vis longueur 38mm x 4
N. Vis longueur 19mm x 2
ASSEMBLAGE
Retirez toutes les pièces de leur
emballage et procédez comme suit :
Fig.2 – Positionnez un des tubes
d'acier (I) dans un des trous situés
dans la poignée (J). Faites tourner
le tube afin que les trous de vis
correspondent, puis vissez en place
à l'aide d'une des vis de 38mm de
long (M). Répétez l'opération pour
le deuxième tube.
Fig.3 – Positionnez le porte
accessoires (K) par-dessus les deux
tubes d'acier comme indiqué, et
vissez-le à la poignée à l'aide des
deux vis de 19mm de long (N).
™
