Basic Overview

DIGICAT Display Panel and Controls

en
1. Mode Indicators
Displays the selected mode (as
shown, from bottom to top) Power,
Radio or Generator 8KHz - 33KHz)
2. Mode Control
Selects and indicates the
DIGICAT operating mode
3. Battery Indicator
Gives an indication when less than
20% battery life remains.
TM
DIGICAT
100 - 1.0.0en
1
2
5
4. Meter display
Indicates the response of the
DIGICAT to a signal.
5. Pinpoint Up Control
Used in conjunction with the speakers
to accurately determine the position of
the service.
6. Pinpoint Down Control
Used in conjunction with the speakers
to accurately determine the position of
the service.
8
3
4
6
Basic Overview
