USING BLUETOOTH, ANALOG AND OPTICAL
To play music via Bluetooth, first select BT as the
speaker's source. Once selected, the BT light will pulse
indicating it is ready to pair. Enable Bluetooth on your
mobile device and then select the speaker as the device to
complete the pairing. The BT light will remain lit once the
pairing is complete. Press Play in your preferred music
streaming application.
- VOL + VOL PAUSE
Note: The speaker's source must be set to BT in order for
it to be discoverable within the Bluetooth settings on your
mobile device. The speaker and your mobile device will not
auto connect.
If the speaker is muted in a wired connection source, the
AUX or OPT light will slow pulse.
The speaker has an Auxiliary Analog Audio and TOSLINK
Optical Audio inputs, which are compatible with devices
that have similar auxiliary and optical outputs.
BACK OF SPEAKER
14
CAST
BT
AUX
SOURCE
OPT
AUX OPT
SETTING UP A STEREO PAIR
To create a stereo pair between two MA770 speakers,
first make sure they are both connected to the same WiFi
network. Hold down the -VOL and PAUSE buttons on the
left speaker for four seconds. All four SOURCE lights will
pulse indicating pairing is activated. Hold down the +VOL
and PAUSE buttons on the right speaker for four seconds.
All four SOURCE lights will remain solid for two seconds
indicating that you've successfully created a stereo pair.
The stereo pair will be named after the left speaker with
the word "pair" added to the end. This pairing will be visible
when connecting to the speaker via Cast and Bluetooth on
your mobile device.
If the pairing has failed, the lights on each speaker will
quickly flash and then turn off. To cancel this setup, press
and hold the PAUSE button for four seconds.
Note: When speakers are in stereo pair mode, only the
left speaker can receive wired inputs. However, the
volumes are synced and the controls of both speakers
work together.
STEP 1
EN
STEP 2
15
