Hardware Overview
Antenna
Connects to a
wireless network.
Dismount Button
Press to safely remove USB
drives from the DSM-G600.
USB 2.0 Ports
Use these ports to connect USB 2.0 drives.
USB 1.1 drives may also be connected but
will be limited to USB 1.1 speed.
4

Rear Panel

Reset Button
Pressing the reset button for 10 seconds with
a paper clip will restore the unit to the original
factory default settings. The button is inside the
hole to prevent an accidental reset.
Power Receptor
Receptor for the supplied
power adapter.
LAN Port
Connects to your Ethernet network. The LAN port
supports Auto MDI/MDI-X, allowing you to connect a
straight-through or crossover cable.
Fan/Vent
Fan to cool the internal
hard drive.
