Schema Di Collegamento - Quick REV 001a Benutzerhandbuch Und Wartung

QCC-DRV CH4 - REV001A

SCHEMA DI COLLEGAMENTO

CONNECTION DIAGRAMS - SCHÉMAS DE BRANCHEMENT - ANSCHLUSSPLÄNE - ESQUEMAS DE CONEXIÓN
QUICK SPA
INPUT: 10÷30VDC OUTPUT: DMX512
8mm wire preparation 0.5-1.5
2
POWER INPUT DMX OUTPUT
DC + DC - A + B - GND
- NEGATIVE
VIN: 10÷30VDC
+ POSITIVE
17
DMX512
OUTPUT
