Installation Instructions - USRobotics USR805436A Installationsanleitung

English
Requirements
! A computer with an Ethernet internet connection
! The Installation CD-ROM that came with your printer
! An HTML 4.01-compliant Web Browser (such as Internet Explorer 5.5 or
later or Netscape 8.0 or later) with JavaScript enabled
! Ethernet cable
! USB cable

Installation Instructions

Step One: Connect the Wireless USB Print Server
N o te : The Wireless USB Print Server must be connected to your network using
an Ethernet cable for the initial configuration. After the initial configura-
tion, you can establish a wireless connection to the network.
1. Turn on your printer.
2. Connect one end of the USB cable to the USB port on your printer, and con-
nect the other end to the
3. Connect one end of the Ethernet cable to your router and the other end to
the port on the print server.
LAN
2
port on the print server.
USB
