EN-6 Chapter 1
Figure 1-3 Adjusting the Height and Tilt
To raise the monitor:
1. Hold the monitor along the bottom or right edge with your right
hand.
2. Grip the left side of the monitor with your left hand and pull the
lever behind the monitor toward you, while raising the monitor
to the desired height.
To lower the monitor:
1. Pull the lever behind the monitor toward you with your left hand
and immediately release the lever.
Each time you pull the lever, the monitor lowers one step.
There are 10 stops total and each stop is about 3/8 inch
(9.5 mm) lower than the previous one.
2. Repeat this step until you find the desired height, or hold the
lever in the depressed position until it reaches the height you
want.
To adjust the tilt, hold the monitor on both sides and tilt it forward or
back until you find the best viewing angle.
