Interlogix EV1012PI Installationsanleitung

EV1012PI PIR Detector Installation Sheet
EN DA DE ES FI FR
1
3
© 2019 UTC Fire & Security Americas Corporation, Inc.
IT NL NO PL PT SV
2
4
12 m range (39 ft. 4 in.)
8 m (26 ft. 2 in.)
6 m (19 ft. 8 in.)
4 m (13 ft. 1 in.)
2 m (6 ft. 6 in.)
0 m
2 m (6 ft. 6 in.)
4 m (13 ft. 1 in.)
6 m (19 ft. 8 in.)
8 m (26 ft. 2 in.)
2.4 m (7 ft. 10 in.)
(optimum)
Note: For UL/cUL compliant installations please note an undercrawl
zone of 4 feet
P/N 146253999-6 (ML) • REV D • ISS 07MAR19
1 / 20
(1)
(3)
1 2.0 m (39 ft. 4 in.)
(2)
