Important Information
The AP features 5 LAN ports and one of LAN port behave as a WAN port when setup the Gateway mode to
use.
TX output power is limited to 20dBm (EU) 23dBm (FCC) , up to 25dBm (South America)
The AP mode's default IP address is 192.168.100.252
The default Subnet Mask is 255.255.255.0
The default SSID is airlive
The default Channel is 11
The default login username is admin and no needed to enter the password, you can change the password
in the Web configuration page
In AP, Client, Bridge, and Repeater mode, the default DHCP Server is disabled. Please set your PC's IP
address to the same subnet as the AP to access the AP.
In WISP mode and WISP+Universal mode, the DHCP server is enabled. Please restart your PC to renew
the IP address.
Support of 8 modes of wireless functions :
AP, Client, Bridge, WDS Repeater, Universal Repeater, WISP (Client Router), WISP + Universal
Repeater and Gateway (AP Router) mode
Note: If you setup the wireless mode and push the setup button, but can't pop-up window, please disable
the pop-up block function of the Yahoo or Google toolbar to allow pop-up window on your browser.
GPL Compliance: Part of the device's firmware use GPL licensed code. There is no warranty for the GPL
software. You can get a copy of the GPL source code from our website at http://www.airlive.com/gpl.htm.
