Voltage-Controlled Filter
Adjustable parameters include the 24-db low-pass filter, "ARP" and
"MOOG" modes, cutoff, and resonance. In addition, you can select
three of six available modulation sources.
VCF Frequency: The cutoff frequency of the low-pass filter is the
frequency above which the spectrum is attenuated and overtones
are de-emphasized. This is where you manually change the cutoff
frequency.
VCF Resonance
Resonance results from feeding the filter output back to the filter
input: the frequencies near the cutoff frequency are thus emphasi-
zed. At full resonance the filter self-oscillates and creates a sine
wave at the set cutoff frequency.
VCF Modulation
The filter cutoff features three modulators that can be adjusted
according to intensity. There are three faders to adjust the intensi-
ties and three switches to select the sources. You can use a selec-
tor switch directly below each fader to choose the signal to be
mixed. For the first modulator you can select from Key Follow and
the Sample/Hold mixer, or alternatively the connected foot slider
(read the explanation below). For the second modulator you can
select from the Sample/Hold function and the LFO's sine wave. For
the third modulator you can select either the AR or the ADSR enve-
lope.
